NextSeq 1000/2000 P1 Reagents (100 循环)
20074933
您可以点击此处，找到Illumina公共数据页面。
访问该数据需要登录BaseSpace Sequence Hub。
注册BaseSpace Sequence Hub账号
| NextSeq 550 系统 | NextSeq 2000 系统运行 1 | NextSeq 2000 系统运行 2 | |
|---|---|---|---|
| 主要运行指标 | |||
| 双端read PF | 514.2M | 518.3M | 532.8M |
| 产量 | 103.9 Gb | 103.7 Gb | 106.5 Gb |
| 错误率 | 0.34% | 0.32% | 0.30% |
| 二级分析指标 | |||
| 常染色体基因检出率 | 95.61% | 95.95% | 95.94% |
| 匹配read百分比 | 99.15% | 99.08% | 99.07% |
| 平均靶点覆盖深度 | 78.05 | 77.85 | 78.15 |
| 覆盖度均一性 | 93.20% | 93.23% | 93.28% |
| SNV查准率 | 99.3% | 99.3% | 99.33% |
| SNV查全率 | 94.1% | 94.2% | 94.27% |
| 插入缺失查准率 | 88.0% | 89.3% | 89.19% |
| 插入缺失查全率 | 83.3% | 84.7% | 84.75% |
| NextSeq 550 系统 | NextSeq 2000 系统运行 1 | NextSeq 2000 系统运行 2 | |
|---|---|---|---|
| 指标 | |||
| 双端read PF | 422.4M | 511.6M | 523.7M |
| 产量 | 63.6 Gb | 76.76 Gb | 78.25 Gb |
| 错误率 | 0.27% | 0.27% | 0.33% |
| 平均检测到的基因数量 (n = 24) | 24,355 | 24,284 | 24,357 |
图1：高度一致的mRNA-Seq结果 使用NextSeq 550系统通过细胞群mRNA-Seq对特定的RNA靶点进行定量，并绘制在y轴上。NextSeq 2000系统的结果绘制在x轴上。沿着y = x趋势线观察数据的一致性（四个重复的R<466>2 > 0.99）。
| 读长 | NextSeq 1000/2000 P1 Reagents | NextSeq 1000/2000 P2 Reagents | NextSeq 2000 P3 Reagents |
|---|---|---|---|
| 每个流动槽的产出a | |||
| 1 × 50 bp (P3 only) | 60 Gb | ||
| 2 × 50 bp | 40 Gb | 120 Gb | |
| 2 × 100 bp | 80 Gb | 240 Gb | |
| 2 × 150 bp | 30 Gb | 120 Gb | 360 Gb |
| 质量分值 | 100M | 400M | 1.2B |
| Quality scoresb | |||
| 1 × 50 bp | ≥ 90% 的碱基分值高于Q30 | ||
| 2 × 50 bp | ≥ 90% 的碱基分值高于Q30 | ||
| 2 × 100 bp | ≥ 85% 的碱基分值高于Q30 | ||
| 2 × 150 bp | ≥ 85% 的碱基分值高于Q30 | ||
| 运行时间 | |||
| 1 × 50 bp | ~11 hours | ||
| 2 × 50 bp | ~13 hours | ~19 hours | |
| 2 × 100 bp | ~21 hours | ~33 hours | |
| 2 × 150 bp | ~19 hours | ~29 hours | ~48 hours |
